- Housing of machine
- Inlet belt
- Transport belt for chocolate enrobing machine with speed regulation
- Pump for recirculation of chocolate mass with speed regulation, with vessel for acceptance of mass surplus
- Enrobing table with regulation of height and width, two chocolate curtains
- Fan for removal of surpluss of chocolate mass with regulation of mass and angle
- System for chocolate enrobing of the product, from lower part with regulation
- System for chocolate enrobing of the product, just from lower part with regulation of layer thickness
- Vibrator for removal of chocolate surplus with speed regulation
- Device for raising of net
- Infrared heaters for heating of internal space
- Axis for removal of tails with speed regulation, two directions of work and heating
- Rolls for removal of chocolate surplus from wire belt
- Agitator of chocolate with cleaning devices and two directions of work
- System for autonomous cleaning
- System for water heating in enrobing machine
- System for process management
- Technical documentation with user and maintenance manual
TECHNICAL CHARACTERISTICS
- Belt width: 600 mm
- Speed of wire belt: 1-3 m/min
- Installed power: 12 kW, 3 x 380 V, 50 Hz
- Outer dimensions of machine: width 1300 mm, length 1800 mm + inlet belt, height 2000 mm
- Material: Č.4580 (AISI 304)
I. COOLING TUNNEL
SYSTEM ELEMENTS
- Inlet part of tunnel with system for automatic conduction of belt (length 1 m)
- Central part of tunnel with two cooling units and channels for air distribution
- Platform with belt carriers and hoods (segments on 2 m)
- Outlet part of tunnel with drive reel and system for belt stringing (length 1,5 m)
- Belt (oily or relief, on client’s request)
- Adjustable height of inlet part of tunnel
- Automatic belt movement
- Technical documentation wit h user and maintenance manual
TECHNICAL CHARACTERISTICS
- Belt width: 600 mm
- Length of cooling part of tunnel: 10 m
- Installed power: 16 kW
- Outer dimensions of machine: width 0.8 m, length 11.5 m, height 1.4 m
- Material: Č.4580 (AISI 304), hoods made of panel plastic and polyurethane
